HYDRO INDUCTION POWER
MICRO HYDRO SYSTEMS
EXAMPLES
The most popular AC/DC System:
    * Hydro: HV1200 w/ 4 Nozzles
    * Gross Head: 180' / Net Head: 166'
    * Pipe: Utility, 2'' Poly
    * Pipe Length: 900'
    * Transmission Line: 1000'
    * Measured Flow: 10 - 40 gpm
    * Power: 500W @ 30gpm

System Costs:

* Intake: $300
    * Pipe: $450
    * Manifold w/ Gate Valves and Pressure Gauge: $150
    * Wire 12/3 UF: $500
    * Hydro Housing (Olive Barrel): $125
    * Hydro HV 1200 w/ 4 Nozzles: $3.600
    * DC Shunt Regulation: $400
    * Installation: +/- 8 Hours
    * TOTAL COST: $5.525 + Installation
Our Home/Shop System:
    * Hydro: HV4000
    * Gross Head: 300' / Net Head: 210'
    * Pipe: Utility, 2'' Poly x 4
    * Pipe Length: 1200'
    * Transmission Line: 400'
    * Measured Flow: 10 - 180 gpm
    * Power: 3800W @ 180gpm
Formulas:

Power (W) = Net Head (ft) x Actual Flow (gpm) / 10

Net Head = Gross Head - (Head Loss x Pipe Length / 100)

Head Loss: see Head Loss Chart
